Our standard chamfered frame style is available in 52mm narrow, 62mm and 70mm standard depths, giving more flexibility when specifying narrower doors.
BENEFIT FROM OUR INNOVATIVE FRAME PROFILE SYSTEM
IMPRESSIVE THERMAL PERFORMANCE
With 8 chambers, our multi-chambered frames give an impressive thermal performance as standard.
ADDED STRUCTURAL STRENGTH
Lead-free profile and plastic thermal reinforcements (PTRs) are both thermally efficient and incredibly strong with the added bonus of being light and quick to install.
IMPROVED WEATHER TIGHTNESS
Our innovative system uses three gaskets to reduce heat loss and improve weather-tightness.
72% BETTER SCREWN RETENTION
With 72% better screw retention than through steel, PTRs offer more secure fixing of hardware keeping your frame rigid, stable and secure
A RANGE OF PROFILE COLOURS AVAILABLE*
*Any RAL colour available
White on White
Rosewood on White
Rosewood on Rosewood
Golden Oak on White
Golden Oak on Golden Oak
Cream on White
Chartwell on White
Anthracite Grey on White
DOOR SIZING OPTIONS
Our door sizes are dependant on the style you choose but most follow the sizing options below. A wide range of frame extenders and panels may be added for non-standard apertures.
| Width | Width | ||||||
|---|---|---|---|---|---|---|---|
| Min (Narrow) | Min (Std) | Max (Narrow) | Max (Std) | Min (Narrow) | Min (Std) | Max (Narrow) | Max (Std) |
| 800mm | 840mm | 984mm | 1020mm | 1962mm | 1980mm | 2070mm | 2088mm |
Note: The above heights do not include a sill, please add 30mm to each if a sill is required
